材料优点: 1, 切口镜面，合并在一起，几乎没有气隙，磁导率远比硅钢、坡莫合金高.
2, 比坡莫合金高的磁饱和感应强度，适用于检测更宽的电流范围.
3, 和坡莫合金相比，性价比高.
4, 容易安装. |
材料的物理性能： 材质 | 铁基纳米晶合金 | 磁饱和感应强度Bs (T) | 1.25 | 磁导率 ( μ) at 0.08 A/m | 80000-200000 | 矫顽力 Hc (A/m) | 0.8 | 居里温度 ( 0C) | 560 | 密度 d （kg/m3） | 7.2x103 |
规格型号： | 涂层尺寸 (mm) | | 型号. | OD | ID | H | 磁导率u | AM-S-473708 | 48 | 36 | 8.5 | >15000 | AM-S-604010 | 61 | 39 | 11 | >15000 | AM-S-755510 | 76 | 54 | 11 | >15000 | AM-S-806010 | 81 | 58 | 11 | >15000 | AM-S-806012 | 81 | 58 | 13 | >15000 | AM-S-976525 | 98 | 63 | 26 | >15000 | AM-S-1008012 | 101 | 79 | 13 | >15000 |
Attention: All the data listed in this catalogue are got from optimum-annealed samples. When these ribbons are made into cores, there may be some variation of the property according to processing technique. All the data here are only for references, but not for guaranty of any order. Cores with other specifications can be provided concerning to customer’s demand.
|
